tracer 200

The Tracer 200 robot is a robust and intelligent AMR with advanced cargo transportation capabilities and a smart path planning system. It comes with LiDAR, depth cameras, anti-collision bumpers, and other sensors for autonomous navigation, depth perception, and obstacle avoidance.

tracer high speed AGV

key benefits of tracer 200

easy to operate

The easy-to-use tablet, PC, and vehicle interfaces minimize the learning curve and helps operators focus on the mission at hand, whether it’s surveillance, data collection, or any other application for which the tracer robot is deployed.

stable and safe

The 360-degree safe detection range is a powerful and versatile tool that combines safety, surveillance, and adaptability. This capability is crucial for ensuring the robot’s ability to operate effectively in complex and dynamic environments while keeping human operators informed and in control of the situation.

payload capacity

With a high payload capacity of 200 kg, Tracer can efficiently handle tasks in manufacturing workshops, warehouses, and logistics sorting facilities.

tracer 200 specifications

dimensions	500mm X 800mm X 250mm
base weight	90kg
max payload	200kg
navigation maximum speed	1.5m/s
Motion Mode	two wheel differential
battery life	≥8h
charging time	2h
charging method	Fast battery swapping/manual charging/auto charging
battery parameters	DC24V40Ah
Climbing Angle	5°
Global positioning accuracy	±10mm/±3º
Secondary positioning accuracy	±5mm/±1º
Number of positioning layers	2
Navigation mode	Autonomous navigation based on LiDAR
Battery cycles	After 500 cycles, capacity≥80%
Ground requirments	Hard, flat ground (no water/oil/dust)
Working environment	Temperature: 5-40°C, relative humidity: 10-95RH%
Gaps that can be crossed	Able to cross steps: 20mm, Able to cross gaps: 20mm

Two-Wheel Differential

As a two-wheel differential AGV, Tracer 200 has unique advantages with indoor transportation. The small and flexible structure enables it to freely shuttle in various indoor environments and the single handling efficiency has great advantages because of the high payload capacity in combination with the strong power.

flat design

The flat design of Tracer brings extreme carrying capacity. The two-wheel drive puts the universal wheels in motion with the differential rotation and it can freely move in an indoor environment. It is additionally equipped with swing arm independent suspension which allows Tracer to easily overcome small obstacles.
