scout mini
Scout Mini is an all-terrain high-speed UGV with four-wheel differential drive, independent suspension, in-situ differential rotation and other features. This small robot is a versatile platform designed for various industrial tasks. It is equipped with advanced technologies and features that enable it to navigate different environments and gather essential information.
small robot
key benefits of scout mini
quick deployment
The Scout Mini robot can be quickly deployed in various situations, allowing for rapid response and assessment. Its compact size and lightweight design facilitate swift transportation and setup, enabling efficient operations and reducing response times.
maneuverable and versatile
The compact size of the Scout Mini robot enables it to navigate through tight spaces and challenging terrains. It can access areas that may be difficult for larger robots or humans to reach, making it highly maneuverable and versatile.
Stealthy Operations
The small robot size allows it to operate discreetly and quietly, making it suitable for stealthy surveillance operations. It can go unnoticed in sensitive areas, providing valuable intelligence without alerting potential threats.
scout mini technical drawings
robot development kits
![Scout Mini Technical Drawings-03 Small Robot Scout Mini](https://i0.wp.com/indrorobotics.ca/wp-content/uploads/2023/05/Scout-Mini-Technical-Drawings-03.png?resize=1080%2C972&ssl=1)
345mm high
![Scout Mini Technical Drawings-01 Small Robot](https://i0.wp.com/indrorobotics.ca/wp-content/uploads/2023/05/Scout-Mini-Technical-Drawings-01.png?resize=1080%2C1080&ssl=1)
612mm long
![Scout Mini Technical Drawings-02 AgileX Small Robots](https://i0.wp.com/indrorobotics.ca/wp-content/uploads/2023/05/Scout-Mini-Technical-Drawings-02.png?resize=1080%2C1080&ssl=1)
580mm wide
scout mini specifications
Dimensions | 612L x 245W x 580H mm |
IEC Ingress Rating | IP22 |
Weight | 23kg |
Payload Capacity | 10kg (Standard Wheel) 20kg (Mecanum Wheel) |
Top Speed | 10k/h (Standard Wheel) 2.8km/h (Mecanum Wheel) |
Runtime | Up to 8h |
Charging Time | 2h |
Operational Temperature Range | -10°C-45°C |
Max Climbing Grade | 30° (full payload) |
Obstacle Clearance | 70mm (Standard Wheel) |
Ground Clearance | 115mm |
Drive Motor | Hall Encoder |
Battery | 24V 15Ah Lithium |
Communication Interface | CAN Bus |
Steering | Differential |
![small robot scout mini](https://i0.wp.com/indrorobotics.ca/wp-content/uploads/2023/05/Product-Catalogue-Scout-Mini-2.1.jpg?resize=780%2C780&ssl=1)
![AgileX Scout Mini](https://i0.wp.com/indrorobotics.ca/wp-content/uploads/2023/05/Product-Catalogue-Scout-Mini-2.2.jpg?resize=780%2C780&ssl=1)
![Small Robot agilex scout mini](https://i0.wp.com/indrorobotics.ca/wp-content/uploads/2023/05/Product-Catalogue-Scout-Mini-2.6-copy.jpg?resize=780%2C780&ssl=1)
![Small Robot agilex scout mini](https://i0.wp.com/indrorobotics.ca/wp-content/uploads/2023/05/Product-Catalogue-Scout-Mini-2.jpg?resize=780%2C780&ssl=1)
documents and downloads
seamless integration with
indro and scout mini
