By Scott Simmie



A drone detection system described as “probably the best at any airport in the country” played a role in ensuring the safety of Air Force One during Joe Biden’s first visit as US President to Canada.

InDro Robotics is one of the key technology partners, supplying drone detection hardware and software for the Ottawa International Airport (YOW) Drone Detection Pilot Project. It detects drone flights both near YOW and much further afield.

In advance of President Biden’s visit, The US Secret Service, as well as an advance team from Air Force One, visited YOW as part of advance preparations.

The teams wanted to be briefed on airport security, including security measures for the skies and the airport grounds. That included learning about the capabilities of YOW’s Drone Detection Pilot Project – which has been accurately detecting drones at the airport and beyond for years. The program has gained significant media attention – including a cover story for WINGS magazine in 2022:

Drone detection

DRONE DETECTION



When the Secret Service and those involved with Air Force One visited YOW on an advance reconnaissance trip, one of the first questions asked was about drones.

“They asked do we have a drone detection capability – and we were quite proud to tell them that we have probably the best at any airport in the country,” says Michael Beaudette, VP of Security, Emergency Management and Customer Transportation at YOW.

“It provides us with situational awareness not only of the immediate area, but throughout the National Capital Region up to almost 40 kilometres.”

Certain areas of Ottawa’s downtown core are designated restricted airspace because of the House of Commons, Embassies and other sensitive locations.

“During his (Biden’s) visit we paid particular attention to anything flying near the Ottawa airport or downtown,” says Beaudette. “Law enforcement are aware of the capabilities we have. It’s a good partnership and we were happy to be able to give something back to the police and intelligence services.”



THE INDRO CONNECTION

InDro provides core technology for the drone detection system. Other technology partners include Accipiter Radar, Aerial Armor and Skycope – a Canadian firm whose tech includes a database of unique RF signatures emitted by multiple brands of drones. NAV Canada is part of the project, and Transport Canada is kept in the loop on the data generated by the operation.

The effectiveness of the system was proven during the massive convoy protest in downtown Ottawa early in 2022. It detected multiple flights of drones in restricted airspace where UAVs are not permitted to fly. Those detections were covered by the Ottawa Citizen.

Below: Some of the data captured during the 2022 convoy protest in Ottawa. A wealth of data on illegal drone flights was captured:

Drone Detection

ONGOING DETECTION



The system runs 24/7, and is capable of triggering an alert whenever a drone intrusion is detected. In mid-March, 2023, a week prior to the US President’s visit, the system indicated an attempted drone intrusion on airport property.

“The alarms went off and they were tracking it – but because of the geofence around the airport, the pilot couldn’t get control of the drone and put it back down again and departed airport property,” says Beaudette.

“That one’s in our investigations right now. Anything that happens a week out from the visit we look at it very closely. Is it someone doing a rehearsal to detect weak points? Is it a plane enthusiast having a look? Someone who bought a new drone at Costco and decided to try it out? While it’s a little more challenging because the individual left, we did get a license plate and we’re now just connecting the dots.”



A SIGNIFICANT INTRUSION



That’s not the only recent intrusion. In December of 2022, there was a much more serious incident.

A pilot popped up a drone directly in the vicinity of YOW runways, flying within a couple of hundred feet of where planes were landing. It was also a larger drone, which would have almost certainly caused damage were there a collision with crewed aircraft.

The system was capable of not only detecting the drone, but pinpointing the location of the pilot. Law enforcement was immediately dispatched, and the pilot was caught in the act.

Wary of recent global incidents, authorities at YOW kept a very close watch during the US Presidential visit:

“We’ve seen a lot of incidents where drones can pose a significant threat, and certainly the war in Ukraine has advanced the offensive nature of drone use considerably,” says Beaudette. “There’s also recent footage of drone infiltration into Russian military installations where they were able to land a drone on top of an aircraft undetected. So you really have to have the capability to detect and respond to those threats.”

While the system does not have mitigation capabilities at this point (jamming RF frequencies is very complex under Canadian regulations except in extraordinary circumstances), the system is highly capable of real-time drone detection and identification, as well as pinpointing the position of the operator.

Below: Michael Beaudette, VP of Security, Emergency Management and Customer Transportation at the Ottawa International Airport, during an interview with Scott Simmie



Drone Detection

EYES ON THE SKY

The system did detect some drone activity in the National Capital Region during President Biden’s visit, but nothing that was deemed to pose a threat.

Below: President Biden meets with Canadian Prime Minister Justin Trudeau March 23, 2023. Image via Prime Minister Trudeau’s Twitter account:

President Biden

MISSION ACCOMPLISHED

President Biden, along with his aides and a media contingent, departed YOW the evening of March 24.

No drone flights were detected at the Ottawa International Airport during the visit.

“There’s been nothing that looks like it’s targeting the airport or wanting to get a look at Air Force One,” said Beaudette at the close of the Presidential trip.

Below: File photo of US President Joe Biden boarding Air Force One.

President Joe Biden

INDRO’S TAKE

InDro was, obviously, pleased there were no drone incursions at YOW during the visit by the US President. But it’s nice to know there was a system in place that could have detected any drone flights during this important visit.

“The Drone Detection Pilot Project has proven its worth since its inception,” says InDro Robotics CEO Philip Reece. “Getting no detections and being assured there’s no potential threat is just as valuable as identifying incursions – especially during a high-security event such as this.

“We’re proud of this ongoing project and our partnership with YOW, NAV Canada, and our technology partners Accipiter, Aerial Armor and Skycope. We believe this has proven to be an effective model, and one that could be deployed with confidence at other major airports or sensitive facilities.”

Reports are generated on a monthly basis by the YOW drone detection system; we’ll be sure to update you when news warrants. And speaking of that, we issued a news release on this as well. You can download it here.

CONTACT

INDRO ROBOTICS
305, 31 Bastion Square,
Victoria, BC, V8W 1J1

P: 1-844-GOINDRO
(1-844-464-6376)

E: Info@InDroRobotics.com

copyright 2022 © InDro Robotics all rights reserved

CONTACT

INDRO ROBOTICS
305, 31 Bastion Square,
Victoria, BC, V8W 1J1

P: 1-844-GOINDRO
(1-844-464-6376)

E: Info@InDroRobotics.com

copyright 2022 © InDro Robotics all rights reserved

YOW drone detection program featured in WINGS magazine

YOW drone detection program featured in WINGS magazine

The Drone Detection Pilot Project being carried out at the Ottawa International Airport has received some traction in WINGS Magazine, Canada’s leading online and print publication about the aviation world.

InDro Robotics is one of the partners in the project at YOW, supplying hardware and software used to detect drones that might pose a threat to passenger, private and cargo aircraft using the airport. The program has gathered a lot of valuable data since it began in the fall of 2019.

But what it gathered during the anti-vaccine mandate protests in Ottawa in February of 2022 really raised some eyebrows. Drones were detected flying in a restricted flight zone over Parliament Hill and elsewhere in the downtown Ottawa core, with a spike during police operations to clear the protests.

A total of 27 different drones carried out 59 flights over a period of four days. Of those, 25 flights exceeded 400’ above ground level (Transport Canada’s limit, except in special circumstances). Eleven flights took place during hours of darkness – though that’s not a violation of regulations providing the drone is using lights that allow the pilot to maintain Visual Line of Sight and orientation.

Nonetheless, these flights all took place in restricted airspace. A small number were carried out by law enforcement, but the vast majority were not. As you’ll see in the following graphic, 15 unique drone IDs were detected, and 25 of the 59 flights were carried out above 400 feet (including one at 1583′ AGL).

Drone Detection

Wake-up call



Our initial story about this caused quite a stir, including this article in the Ottawa Citizen – along with attention from Canadian airports that do not currently have drone detection programs. And now, WINGS Magazine has picked it up.

The article appears in the May/June Digital Edition, which is also a print edition.

Drone detection

Drone detection, made simple



The system in place at YOW includes a micro-Doppler radar, capable of detecting the movement of small drone propellors at close range. It also features a sophisticated antennae array, which has been picking up flights as far as 40-50 kilometres from the airport.

The system is automated – and the data is banked. If a drone poses an immediate threat to a flight path, an alert is sounded and airport authorities can quickly respond.

You can read the story that appears in WINGS Magazine here. We’d also like to thank editor Jon Robinson for picking this up.

InDro’s take



We’ve pleased to be an integral part of the YOW Drone Detection Pilot Project. The results have been greater than we all anticipated, with highly granular data that has helped YOW educate drone pilots and also prepare an airport protocol for those rare but critical occasions when RPAS flights have the potential to impinge on the safety of crewed aircraft. The system provides enough advance warning that aircraft pilots can be given a heads-up and instructions to minimise any conflict with drones; the system is also capable of identifying the location of the RPAS pilot.

Monthly data is shared with program partners and has generated interest from other Canadian airports. The data detected during the Ottawa protests has also attracted the interest of those responsible for the safety of Parliament Hill and other critical buildings in the downtown Ottawa core.

For more information on how a drone detection system might benefit your airport or critical infrastructure, please don’t hesitate to contact us here.

YOW drone detection program reveals surprising data during final days of Ottawa protests

YOW drone detection program reveals surprising data during final days of Ottawa protests

By Scott Simmie, InDro Robotics



Scores of drone flights took place in restricted airspace – what you might think of as a ‘No-Fly Zone’ – over Parliament Hill in Ottawa during the police operation to clear anti-vaccine mandate protests in February of 2022. While some of those flights were carried out by law enforcement, most flights were illegal and in violation of Transport Canada regulations.

Data collected by the Ottawa International Airport Authority’s (YOW) Drone Detection Pilot Project reveals an incredible spike in flights – a total of 59 – during the days when police were actively clearing protestors from the site.

“In an average month, you’d probably see half a dozen flights (in that same area),” says Michael Beaudette, Ottawa International Airport’s Vice President for Security, Emergency Management and Customer Transportation.

A total of 27 different drones carried out those 59 flights over a period of four days. Of those, 25 flights exceeded 400’ above ground level (Transport Canada’s limit, except in special circumstances), with some flying more than 1500’ AGL. Eleven flights took place during hours of darkness at night – though that’s not a violation of regulations providing the drone is using lights that allow the pilot to maintain Visual Line of Sight and orientation.

While a number of those flights were likely curious hobbyists either ignorant of or willfully ignoring regulations, it’s believed at least some were likely piloted by protestors or supporters seeking to gain intelligence of police movements.

“The majority of those drones were not police or First Responder drones,” says Beaudette. “Some of them could have been looky-loos – just trying to see – or it could have been people wanting to know where the police were forming up.”

Drone Detection

Drone flights, with identifying data redacted, via YOW



Restricted airspace



The airspace above Parliament Hill (as well as 24 Sussex Drive and Rideau Hall) is restricted to all aircraft – crewed and uncrewed – unless special authorization is obtained. In terms of drones, only law enforcement or other First Responders would have legal permission to fly except in special circumstances.

The data was obtained by Ottawa International Airport as part of a broader pilot project aimed at understanding drone traffic in proximity of the airport and developing protocols for aviation safety in the drone era. InDro Robotics is one of the partners in this project, providing key technology used in drone detection. Transport Canada regulations prohibit the operation of small RPAS within 5.6 kilometres of airports and 1.9 kilometres from helipads, except for pilots holding an advanced certification. Airspace permission is also required. (Drones weighing less than 250 grams are a different case, and we’ll touch on that shortly.)

How the drones were detected



The airport uses two different types of technology for drone detection. The first is a micro-Doppler Radar in conjunction with an automated camera. The system, called Obsidian, comes from the British firm QinetiQ. Its high frequency (9-12 GHz) radar can detect the spinning of propellers on a drone anywhere within a two-kilometre range of the airport. Once detected, a camera automatically zeros in on the drone.

You can get a good sense of how the system works via this QinetiQ video:

The second system has been supplied for the trials free of charge by InDro Robotics. It’s capable of capturing data from drones manufactured by DJI, which account for approximately 75 per cent of all consumer drones.

“Our system electronically ‘interrogates’ each device within its range,” explains InDro CEO Philip Reece. “We can triangulate the drone’s position – and on many models we’re able to also detect the type and serial number of the drone, its takeoff point, flight path, current GPS position and altitude. In addition, we can see where the pilot associated with that drone is located. With this data, YOW can quickly determine whether or not a given drone poses a threat to civil aviation.”

The system was intended to pick up any flights within a 15-kilometre radius of YOW. In practice, however, its range has been far greater.

“When we turned it on, we realized our expectations were far exceeded,” says YOW’s Michael Beaudette. “We were getting hits 40 kilometres plus. It’s really done the heavy lifting for the drone detection project. You can identify where the pilot is, where the drone is, and where they are in real time within 15 or 20 seconds.”

Data collected during the police operation to clear the protest reveals the bulk of the flights were carried out by DJI Mini 2 drones – very small machines that weigh just under 250 grams and which do not require a Transport Canada Remotely Piloted Aircraft System (RPAS) Certificate to operate. Microdrones like these are not prohibited from operation near airports or in controlled airspace if operated safely, but cannot gain access to the restricted airspace near Parliament without prior permission.

Drone Detection

A controversial catalyst



So. What started this project?

The 2018 Gatwick Airport drone incident prompted many airports to take a closer look at the potential threat posed by drones. About 1000 flights were cancelled between December 19 and 21 following reports of two drones being sighted near the runway. Some 140,000 passengers were affected, with a huge economic impact.

The incident remains controversial, because there was never any clear physical evidence that drones had indeed posed a threat. Two people were wrongfully charged, released, and later received a settlement.

What cannot be denied, however, is that the highly disruptive incident was a massive wake-up call to airports worldwide. With an ever-growing number of drones in the air, the question of drone detection and potential mitigation became a pressing topic. If a drone detection system had been in place at Gatwick back then, it would have had concrete data as to whether there was truly a drone threat or not.

A Blue Ribbon Task Force was launched by the Association for Uncrewed Vehicle Systems International (AUVSI) in conjunction with regulators and airport representatives. YOW President and CEO Mark Laroche was a member of the Task Force along with representatives of the Federal Aviation Administration (FAA) and NAV Canada. (Its final report can be found here.)

Gatwick, then, was the catalyst that prompted YOW to start taking a very deep look at the issue.

Below: Gatwick Airport. Image by Mike McBey via Wikimedia Commons

Gatwick Airport

“We wanted to be able to help shape a national drone response protocol for airports, so that we didn’t run into a situation like Gatwick, where we would have to shut down,” says Beaudette. “We didn’t even know if it’s a problem. We had to get some baseline data, some situational awareness.  So we (decided to) focus on drone detection…to identify if it was even a threat.”

DJI, to its credit, has geofencing software that prevents its products from taking off in the immediate vicinity of major airports unless the pilot confirms on the app they have permission to do so. And while that’s useful, the geofencing is highly localized and cannot always prevent a pilot from putting a drone into the takeoff or landing path of an aircraft.

“What causes us concern is when they’re in the flight path,” says Beaudette.

In the fall of 2019, YOW began its pilot project. A news release made the project public in June of 2021, quoting Michael Beaudette as saying: “As an airport operator, we felt it was vitally important that we test systems to detect drones operating on flight paths, near the airport and in other restricted zones to help ensure the safety of air crews and passengers.”

Surprising data

With the InDro and QinetiQ systems up and running, the data started coming in. It was something of a shock.

“This opened our eyes,” says Beaudette. “We had no idea of the drone activity that was taking place.”

There were a lot of drone flights taking place close to YOW.

“In March of 2021, our program detected and reported on 101 drone flights within that 5.6-kilometre radius,” said CEO Mark Laroche in a news release. “April’s numbers were even higher at 167. A number of these were flown during hours of darkness and some exceeding altitudes of 1,600 feet.”

Every month, YOW crunches the data into a comprehensive report sent to Transport Canada, NAV Canada, InDro Robotics and other stakeholders. The report from May of 2021 reveals a steep increase in the number of flights.

Drone detection

The rapid increase was due to warmer weather and the increasing popularity of sub-250 gram drones, which are both more affordable and do not require an RPAS Certificate or registration. Here’s a breakdown of the top 30 drone models detected within a 15-kilometre radius during that same month:

Drone Detection

The monthly report from this period states: “Detecting and identifying ‘drones of concern’ operating in the vicinity of the Ottawa Airport remains one of our primary objectives. This month, there were 19 such drones of concern within the YOW 5.6 km zone. These include drones that flew during hours of darkness, or were over 250 grams and flew over 400 ft. Of these 19 flights, there were 11 unique Drone IDs.”

Because the system can capture drones from even farther afield, other interesting data has emerged during the course of the pilot project.

“We started tracking other locations – Parliament Hill, Gatineau Airport,” says Beaudette. “And we were very surprised to see drones flying at all hours of the day and night and at high altitudes.”

These weren’t just hobby flights. Unusual activity was detected around certain embassies in Ottawa, with the same drones making repeated trips. There were drones flying close to the CHEO and Civic hospital Helipads used by helicopters with the air ambulance service Ornge. There were drones apparently peering into high-rise windows, Peeping-Tom style, and others that appeared to be involved with offering intelligence to people carrying out Break & Enters. (Beaudette says police were notified in some of these instances.)

As part of the Pilot Project, YOW worked with its partners – including NAV Canada, Transport Canada and InDro Robotics – for some real-world exercises. One such test involved determining the accuracy of the detection system. A drone was flown (with all appropriate permissions) from the E.Y. Centre, a massive exhibition/convention facility very close to the airport. When the data captured by the detection system was overlaid with the actual flight log, they were identical. Not only that, but the YOW data precisely identified the location of the pilot.

“We could actually tell which stall in the parking lot (the pilot was standing in),” says Beaudette.

Mitigation



Detection is one thing, but drone mitigation is quite something else. There are systems capable of jamming the Command and Control signal between the drone and the controller (including systems from Bravo Zulu Secure part of the InDro group of companies. Here’s a quick overview of how these systems work.

But such systems are not in cards for YOW or other airports in Canada. Quite simply, Transport Canada and Industry Canada (which regulates radio spectrum frequencies) prohibit them in this country except in extraordinary circumstances.

“First and foremost, a drone – like any other airplane – is considered an aircraft,” says Beaudette. “And so Transport Canada has restrictions: Nobody has the authority to interfere with the flight of that aircraft. So you won’t see airports with jammers or other kinetic solutions to that unless they have the proper authority.”

Plus, he emphasizes, the Drone Detection Pilot Project is focused on drone detection. It’s a data-gathering exercise to help formulate protocols, provide useful information for regulators, and alert airport authorities immediately if a drone poses a threat to a flight path. YOW is not the drone police; its primary interest is in ensuring the safety of aircraft using the facility.

“If we can detect something, we may be able to mitigate it by rerouting aircraft, delaying aircraft, or we can locate the pilot,” says Beaudette.

Thankfully, despite many flights violating the 5.6 kilometre radius, YOW has not encountered a drone that posed a serious threat since the program began. Should that occur, it does have protocols in place to ensure civil aviation safety. Plus, of course, Transport Canada has the option of imposing heavy fines on pilots who put aircraft at risk or are flying without a Remotely Piloted Aircraft Certificate. And with the detection system in place, locating an offending pilot would not be difficult.

Know the regs

Ultimately, the biggest piece of the puzzle is around education. Some pilots simply don’t know the rules and unwittingly violate them – an excuse that won’t help them much if facing a fine. YOW has found, for example, that pilots often fly from nearby neighborhoods or golf courses without realizing they’re impinging on that 5.6 kilometre zone.

There’s also the issue of confusion around piloting sub-250 gram drones. Because they do not require an RPAS certificate or registration, many believe the rules somehow don’t apply to them. Yet the over-arching meaning of the regulations is clear: They must not be flown in an unsafe manner. And that includes near airports.

“We actually had a case where we found a drone that crash-landed inside the (airport) fence,” says Beaudette.

“We’re still the proud owners of that drone.”

InDro’s take

Several members of the InDro Robotics team – including our CEO – have expertise as private and commercial pilots. As a result, we have perhaps a heightened awareness of the potential risk drones can cause if they’re in the wrong place at the wrong time. Drone detection at airports and other sensitive facilities is critical, and the deep data collected by YOW reflects that.

We’re proud to be part of the YOW Drone Detection Pilot Project and look forward to assisting others with drone detection and even mitigation, where appropriate. If you’re interested in exploring such a system, we’d be happy to help.
