bunker

Bunker is an industrial robot with a tracked UGV system intended for complex outdoor environments with rugged terrain and applications that require a high payload capacity.

industrial robot

key benefits of bunker

high payload capacity

70kg Payload Capacity

Designed and built to handle and manipulate heavy objects or payloads. Bunker is commonly used in industrial settings, manufacturing, logistics, and other applications where the ability to lift and move substantial loads is required.

rugged ready

IP54 Rating

The high performance track structure, suspension and shock absorbers make it easy for Bunker to conquer mud and rugged terrain. It also has the ability to climb slopes and stairs with ease. The tough industrial robot design is perfect for various complex environments.

adaptable and scalable

ROS1, ROS2, Python and Gazebo

Bunker is supported with ROS1, ROS2, Python and GAZEBO for simulations. The slide rails on top allow for quick building with sensors, controls, cameras, etc. This makes Bunker expandable and adapable for various use cases.

bunker technical drawings

robot development kits

400mm high

1023mm long

778mm wide

bunker specifications

Dimensions	1023mm x 778mm x 400mm
Weight	150kg
Payload	70kg
Operating Temperature	-20°C to 60°C
IP Rating	IP54
Battery	48V30Ah (Upgradable to 40V60Ah)
Charging Time	6 to 7 hours
Operating Time (No Load)	2 hours (30Ah), 4 hours (60Ah)
Range (No Load)	10km
Communication	CAN Interface
Maximum Climbable Obstacle Height (No Load)	170mm
Maximum Climbable Slope (No Load)	36°
Minimum Ground Clearance	90mm
Motors	Two 650W Brushless Motors
