b2 robot
A resilient and high-performance quadruped, the B2 robot is built to excel. Boasting an IP67 rating and substantial load-bearing capacity, this full-sized quadruped effortlessly maneuvers through various conditions and terrain. Its robust internal hardware unleashes a wealth of commercial possibilities, making the B2 an innovative solution for a wide range of applications, from automated manufacturing to precision logistics.
b2 robot quadruped
key benefits of b2 robot
Environmental Resilience
With an IP67 rating, the B2 robot is well-protected against dust and can withstand temporary immersion in water, making it suitable for use in challenging and wet environments.
High-Performance Capabilities
With a substantial load capacity and powerful internal hardware, the B2 robot delivers high-performance results. It can handle complex tasks and offers great potential for commercial functionality.
Versatile Applications
The B2 robot is designed for a wide range of applications, from automated manufacturing to precision logistics. Its versatility allows businesses to adapt it to various tasks, increasing operational efficiency and productivity.
b2 technical drawings
robot development kits
645mm high
1098mm long
450mm wide
b2 specifications
| Size (Standing) | 1098mm x 450mm x 645mm |
| Size (Lying Prone) | 880mm×460mm×330mm |
| Weight | 60kg Total weight (battery included) |
| Battery Performance | Battery capacity 45Ah(2250Wh)，voltage 58V |
| Runtime | Battery life 4-6h | Walking without load > 5h, and the mileage > 20km |
| Wheeled Foot | Optional |
| Load(Standing) | Max. 120kg |
| Load(Walking) | > 40kg |
| Continuous Stair Climbing | Stairs of 20~25cm |
| Single Obstacle Crossing | Climb up and down stairs of 40cm in forward direction |
| Operating Temperature | -20℃ ~ 55℃ |
| Climbing Angle | > 45° |
| Running Speed | > 6m/s [1] |
| Ditch Jumping Width | 0.5~1.2m |
| Max Jump Distance | > 1.6m |
| Ingress Protection | IP67 |
| Control and Perception | Standard Configuration: Intel Core i5 (Platform Function), Intel Core i7 (User Development) | Optional Configuration: Intel Core i7 and Jetson Orin NX (Maximum up to 3 devices) |
| Sensing Sensor | 3D LiDAR ×1 + Depth camera ×2 + Optical camera ×2 (Varies with different configurations) |
| Interface | 1000M-Base-Ethernet×4 USB3.0×4 | 12V×4 5V×1 24V×4 BAT×1 |
